Key information
Description
operates as an active 2-way enclosure, over a frequency bandwidth from 50 Hz to 20 kHz which can
be lowered to 32 Hz with the addition of the SB18 subwoofer
50 Hz - 20 kHz
Nominal directivity (-6dB) 50° Axi-symmetric
Maximum SPL1 139.5 dB ([HiQ_MO] preset)
136.5 dB ([HiQ_FI] preset)
RMS handling capacity LF : 450 W ([HiQ_FI] preset)
HF : 125 W ([HiQ_FI] preset)
Components LF: 1 x 15’’ weather-resistant transducer
HF: 1 x 3’’ diaphragm compression driver
Nominal impedance: 2 x 8 ohms
Physical data H x W x D: 365 x 580 x 440 mm - 14.4 x 22.8 x 17.3 in
Wedge angle: 30° or 60° with regard to vertical
Weight (net): 28.5 kg - 62.8 lbs.
Connectors: 2 x 4-point Speakon®
Material: 18, 24 and 30 mm Baltic birch plywood
Finish: Grey-brown RAL 8019®
Front: polyester-powder coated steel grill,
acoustically transparent Airnet® cloth
Rigging: integrated handles and pole mount socket,
optional ETR15 bracket and XTLIFTBAR accessory
