Input Impedance 20 kohms
Output Impedance <50 ohms source
Total Harmonic Distortion 0.0662 @ 1 kHz
(Measured @ 30 dB gain) Variable Decay Time
Bandwidth 0.06 dB @ 20 Hz
-0.34 DB @ 10 kHz
-0.78 DB @ 20 kHz
-3.00 DB @ 65 kHz
Gain 36 dB
Signal-to-noise ratio -110 EIN
(Rs = 20 k, 40 dB gain)
Maximum Output 20 dB @ 600 ohms
Maximum Compression 26 dB
Variable Attack Time .5 ms - 100 ms
200 ms - 10 s
Tubes 2 - 12AX7, 1 - 12AT7
2 - 12BH7A
XLR Output Jacks, TT & 1 / 4 "
XLR Input Jacks, TT & 1 / 4 "
Mounting space 2 std., 19 "rack
Operating Voltage 117 Volts or 240 Volts
The machine heats up and need to be are! configuration and simple and effective, there is a pumping effect is compressed as a strong background noise (lamps!)
Compression is very effective, with good audio quality. Produced a noise not ngligable!
I use it with the voices and instruments.
I use it for two months, its background ESG me, especially for use in mastering!, Compression is very effective and the sound is very clear.
I can not compare because I have no other machine of the same type.
Do not sell the newer, only on the second hand market.
