ADJ (American DJ) UV COB CANON
Images
1/8

ADJ (American DJ) UV COB CANON

Color Changer from ADJ (American DJ)

Write a user review or Ask for a user review

Buy new ADJ (American DJ) UV COB CANON

  • Thomann In stock / Delivered in 24h €319.00

UV COB CANON classified ad

Send me a notification via email whenever there is a new ad on this product

Images

Tech. sheet

  • Manufacturer: ADJ (American DJ)
  • Model: UV COB CANON
  • Category: Color Changers
  • Added in our database on: 11/19/2014

The UV COB Cannon ADJ produces UV Wash off effect from a UV LED COB high power. COB technology (Chip On Board) increases the power of LEDs using a small place on the board.

This professional projector is designed as WASH for theater productions, large scenes and special effects productions. It only requires a very low maintenance.

The UV COB Cannon has 3 operational modes (music mode, manual mode or DMX mode), 5 gradation curves, LED display with 4 navigation buttons is operated flicker for use in TV production and film. It is chainable via its inputs and outputs DMX and Powercon. Its source is a COB LED Cluster 9x6 (54) LEDs 1.5W cool white (8,000K).


     Product Description
     Additional Information
     Documents
     videos

specifications:
- Canon hyperpuissant LED UV LED
- Ideal for large stages, theatrical productions and special effects
- Almost no maintenance: low consumption, low heat
- Technology COB (Chip On Board) Advanced produces a white light high power
- 3 Operational modes: Sound Active mode, manual mode and DMX
- 3 DMX modes: 1, 2 or 3 DMX channels
- Viewing 4 navigation buttons
- Flicker (for TV production)
- 5 gradation curves available: Standard, Stage, TV, Architectural & Theatre)
- Pulsating strobe effect and
- Electronic Dimming: 0 - 100%
- Beamwidth angle: 33 degrees
- Double suspension yoke to mount the gun structure or put it down
- Chaining DMX: XLR 3-pin
- Chaining the current: PowerCon (up to 3 Lighting COB Cannon @ 120V 5 Lighting COB Cannon's @ 220V)
- Long-lived LEDs estimated at 25,000 hours)
- Power consumption: 110W total (all LED's @ Full)
- LED Source: 9x6 1.5-Watt UV LEDs, COB (80W total)
- Multi-voltage Power: AC 100-240V, 50Hz / 60Hz
- Dimensions (LxWxH): 131x200x324mm
- Weight: 4.32kgs


ADJ - UV LED COB Cannon

»
