Varytec WIND UP 85KG

Technical specifications:
• Max. height: 4 m
• Max. load: 85 kg
• Mounting: 1 3/8"
(for speakers with a 35 mm flange)
• Weight: 25 kg
• Tripod width: max. 1.6 m
• Transport dimension: 1.75 m
Truss beam dimensions:
• 1300 mm × 35 mm × 35 mm
(optional truss adapter: Thomann item no. 337351)

• Loosen the locking screws for adjusting the tripod width and the mounting height of the extension tube and pull out the fixing bolts.
• Put the fixing bolts in the desired height into the borehole of the tripod bar and re-tighten the locking screws.
• Check all locking screws and fixing bolts for tightness before using the tripod.
• Use the hand crank with wire rope hoist for adjusting the desired height of the mounted truss or the box.

Ensure that plastic bags, packaging, etc. are properly disposed
of and are not in the reach of babies and young children.
Choking hazard!

For the packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. Please follow the notes and markings on the packaging.
